| Item | Parameter |
|---|---|
| Center Frequency | 975 ± 30 KHZ |
| Resonant Impedance | <150 Ω |
| Capacitance | 1000 ± 25% pf at 1 KHZ |
| Pressure Resistance | < 2.6 Mpa |
| Launching Beam Angle | 5° - 10° |
| Receptive Sensitivity | ≥ 200 mv (semi-wave) |
| Housing Material | High Polymer |
| Sealing | Sealed with epoxy resin |
| Wiring | Twin-wired |
| IP Level | IP68 |
